MegaMeter™ Measures Gravity Flow Up
to 22,200 GPH/185,000 #/HR. |
Infinite Rangeability
Guarantees 100% Accuracy
With Flows As Low As One Drop At A Time. |
- Gravity flows of liquid are accurately measured with
Mega-Meter's volumetric drum. "Volumetric" means we measure the liquid by
volume, corrected for temperature, not rate of flow.
Since the volume of each six chamber drum is a known factor, counting revolutions is 100%
accurate. Construction is 304SS.
|
 |
| Typical applications: Waste water treatment
plant discharge; central steam plant condensate return; absorption chillers; irrigation
monitoring; portable water return lines; pretreated industrial wastewater. |
| How The Lincoln™ Meter
Works |
| The drum consists of six scroll-shaped sections.
Liquid enters the drum through an axially mounted inlet spout at the center of the |
meter. As each section fills, excess water
spills in to the next section. This shifts the center of gravity and the drum rotates. |
HOW TO ORDER
MEGAMETER SIZES H-M |
METER TYPE: CONDENSATE ______ LIQUID
______ SIZE ______
PPH ______ GPH ______
|
| SIZE |
CAPACITY |
INLET |
OUTLET |
A |
B |
C |
D |
E |
F |
G |
H |
WT. |
SHP. |
| |
PPH |
NPT |
NPT |
|
|
|
|
|
|
|
|
|
WT. |
| H |
18,565 |
3" |
5" |
52 5/8" |
48" |
17 1/4" |
4 7/8" |
22 |
51 1/2" |
33 5/8" |
19" |
725 |
750 |
| gph |
2,227 |
|
|
|
|
|
|
|
|
|
|
|
|
| I |
37,130 |
3" |
5" |
52 5/8" |
48" |
23 1/4" |
4 7/8" |
22 |
51 1/2" |
33 5/8" |
19" |
800 |
840 |
| gph |
4,454 |
|
|
|
|
|
|
|
|
|
|
|
|
| J |
69,000 |
4" |
6" |
52 5/8" |
48" |
33 1/4" |
6" |
22 |
51 1/2" |
33 5/8" |
19" |
925 |
985 |
| gph |
8,277 |
|
|
|
|
|
|
|
|
|
|
|
|
| K |
100,000 |
4" |
6" |
52 5/8" |
48" |
43 1/4" |
6" |
22 |
51 1/2" |
33 5/8" |
19" |
1,200 |
1,275 |
| gph |
11,953 |
|
|
|
|
|
|
|
|
|
|
|
|
| L |
140,000 |
6" |
8" |
52 5/8" |
48" |
56 1/2" |
7 1/4" |
22 |
51 1/2" |
33 5/8" |
19" |
1,700 |
1,790 |
| gph |
16,795 |
|
|
|
|
|
|
|
|
|
|
|
|
| M |
185,000 |
6" |
8" |
52 5/8" |
48" |
72" |
7 1/4" |
22 |
51 1/2" |
33 5/8" |
19" |
2,000 |
2,125 |
| gph |
22,193 |
|
|
|
|
|
|
|
|
|
|
|
|
|
